BendPak 1302BA-DLX-601 : DA Tube Bender, 302 Tooling Pkg

Write a Review
$13,595.00
SKU: 5115121
Type: Digital-Automatic
Motor: 208-230V
Tool Package: Deluxe 302
Ph: 1
Adding to cart… The item has been added

The BendPak 1302BA-DLX-601 Digital Automatic Tube Bender is a commercial-grade hydraulic bending machine designed for precision exhaust pipe fabrication, custom tubing applications, and high-volume automotive service operations. Featuring a programmable digital control system, powerful 5 HP motor, and high-speed 4 GPM hydraulic pump, this tube bender delivers accurate, consistent, and efficient bending performance for professional workshops.

Engineered for busy muffler shops, automotive fabrication facilities, and custom exhaust specialists, the 1302BA-DLX-601 offers both automatic and manual bending functions. Its advanced digital control system stores up to 99 bend-depth settings, allowing operators to reproduce bending configurations with greater consistency while reducing setup time for repetitive fabrication tasks.

Equipped with dual rear-mounted end-finishing units, a high-speed clampless swager, and an internal expander, this machine supports professional tube bending, flaring, expanding, and swaging operations. Its quick-release bending dies, twist-lock tooling, and convenient drop-in collar simplify tooling changes and improve workflow efficiency.

Built with a rigid 6" x 6" x 3/8" welded-steel frame, commercial-grade hydraulic cylinders, and precision-ground bending heads, the BendPak 1302BA-DLX-601 is designed for demanding fabrication environments. Additional features such as industrial-grade casters, hydraulic pressure gauges, enclosed controls, and integrated tool trays enhance convenience, durability, and workshop productivity.

Key Features:

  • Digital Automatic Bending System: Provides programmable control for accurate and repeatable tube bending operations.
  • 99 Bend-Depth Memory Settings: Stores up to 99 bending configurations for convenient setup and repetitive fabrication.
  • Automatic and Manual Operation: Allows operators to select the appropriate bending mode for different applications.
  • 302 Tooling Package: Supplied with tooling for professional exhaust pipe bending and finishing applications.
  • Powerful 5 HP Motor: Delivers dependable hydraulic power for demanding fabrication tasks.
  • High-Speed Hydraulic Pump: Direct-drive, 4 GPM pump supports efficient bending performance.
  • Dual End-Finishing Units: Two rear-mounted units provide tube flaring and expanding capabilities.
  • High-Speed Clampless Swager: Simplifies and accelerates tube swaging operations.
  • Internal Tube Expander: Supports precise tube expansion for custom exhaust fabrication.
  • Open-Sided Swager Box: Improves tooling accessibility and helps reduce accidental tool interference.
  • Quick-Release Bending Dies: Reduce setup time and simplify tooling changes.
  • Twist-Lock Tooling System: Allows convenient installation and adjustment of bending accessories.
  • Drop-In Swaging Collar: Helps make swaging operations quick and efficient.
  • Precision-Ground Bending Heads: Ground to within 0.002" for accurate bending performance.
  • Heavy-Duty Welded-Steel Frame: Features rigid 6" x 6" x 3/8" structural steel construction.
  • Commercial-Grade Hydraulic Cylinders: Designed for demanding professional applications.
  • Chrome-Moly Cylinder Shafts: Provide strength and durability during hydraulic operation.
  • Pass-Through Cylinder Stem: Extends through the primary frame as part of the hydraulic bending mechanism.
  • 2.5-Inch Oversized Barrel Shafts: Designed for dependable operation and reduced maintenance.
  • One-Piece Barrel Construction: Helps maintain alignment between the bending gates and ram.
  • Integrated Power-Relief Valve: Provides hydraulic pressure management.
  • Front-Mounted Adjustable Pressure Valve: Allows convenient pressure adjustment.
  • Hydraulic Pressure Gauges: Enable operators to monitor system pressure during operation.
  • NEMA-Rated Electrical Controls: Feature overload relays for electrical protection.
  • Enclosed Control System: Helps maintain an organized bending area.
  • Industrial-Grade Casters: Allow convenient movement and positioning around the workshop.
  • Heat-Treated Tooling: Designed for durability and extended service life.
  • Integrated Tool Trays: Keep bending and finishing accessories organized.
  • Large Hydraulic Reservoir: Supports hydraulic fluid storage and cooling.
  • Canister Oil Filter: Helps maintain clean hydraulic fluid.
  • Oil Sight Gauges: Allow easy visual inspection of hydraulic fluid levels.
  • Oversized High-Pressure Hose: Features a 1/2-inch hydraulic hose for improved flow and cooling.
  • Standard Grease Fittings: Simplify routine lubrication and maintenance.
  • Optional 180° Bending Die: Available for applications requiring additional bending capability.

Technical Highlights:

  • Brand: BendPak
  • Part Number / SKU: 1302BA-DLX-601
  • Product Series: 1302BA
  • Product Type: Digital Automatic Hydraulic Tube and Pipe Bender
  • Tooling Package: 302 Tooling Package
  • Bending Operation: Digital Automatic / Manual
  • Digital Memory Capacity: Up to 99 Bend-Depth Settings
  • Motor Power: 5 HP
  • Hydraulic Pump: Direct-Drive, High-Speed
  • Pump Flow Rate: 4 GPM
  • End-Finishing Configuration: Dual Rear-Mounted Units
  • Swaging System: High-Speed Clampless Swager with Open-Sided Swager Box
  • Expansion System: Internal Tube Expander
  • Tooling Configuration: Quick-Release Bending Dies and Twist-Lock Tooling
  • Frame Construction: 6" x 6" x 3/8" Welded Steel
  • Bending Head Precision: Ground to Within 0.002"
  • Barrel Shaft Diameter: 2.5 Inches
  • Hydraulic Cylinders: Commercial-Grade with Chrome-Moly Shafts
  • Hydraulic Hose Diameter: 1/2 Inch
  • Electrical Controls: NEMA-Rated Switch Box with Overload Protection
  • Mobility: Industrial-Grade Casters
  • Optional Tooling: 180° Bending Die Available
  • Primary Applications: Exhaust Pipe Fabrication, Digital Tube Bending, Swaging, Expanding, and Flaring

The BendPak 1302BA-DLX-601 Digital Automatic Tube Bender combines programmable digital precision, 99 bend-depth memory settings, powerful 5 HP hydraulic performance, and versatile tube finishing capabilities to deliver a comprehensive exhaust fabrication solution. Its heavy-duty construction, efficient tooling system, and automatic bending functionality make it an excellent choice for professional automotive shops seeking consistent results, reduced setup times, and improved fabrication productivity.

Overview

Bending Controls:
Automatic / Digital
Expander Controls:
Manual
Frame Style:
Double-Ended Expander
Max. Tube Capacity:
3" (76 mm) .095 wall

Bending

Max. Bending Radius:
5" (127 mm)
Min. Bending Radius:
3.3" (89 mm)

Hydraulics

Top Cylinder Force:
60,000 lbs. (27,216 kg)
Hydraulic Filter:
Canister
Motor:
5 HP / 208-230 VAC / 60 Hz / 1 PH

Die Pack

Standard:
1.5", 1.75", 1.875", 2", 2.25", 2.5" (302)

Dimensions

Width:
41" (1,041 mm)
Depth:
64" (1,626 mm)
Height:
26" (660 mm)

Shipping

Weight:
1,388
Dimensions:
48" x 70" x 30" (1,219 mm x 1,778 mm x 762 mm)
