8000TLX Extended-Length Portable Truck and SUV Lift
The QuickJack 8000TLX is the highest-capacity, extended-length portable lift in our lineup - engineered specifically for heavy-duty trucks, SUVs, and long-wheelbase vehicles. With an 8,000-lb. capacity and a 66-inch lift point reach, it handles the jobs that standard car lifts can't touch. Built tough, yet fully collapsible, this portable truck lift gives you full access beneath your vehicle without the footprint of a permanent setup.
Despite its size, the 8000TLX still reaches max rise in about 30 seconds, and its low 3.5-inch collapsed height means it fits under most sedans and sports cars too. Add the optional Truck & SUV Adapter Kit for even more undercarriage access on higher-clearance vehicles. Upgrades include a pressure-compensated flow divider for synchronized lifting, reinforced frame geometry, and a factory preassembled hydraulic system. All these improvements ensure faster setup, smoother operation, and maximum durability in the shop or at home.
The 76-inch frames are designed for serious reach but remain compact enough to roll and stow easily using QuickJack's built-in urethane wheels. Take it anywhere - garage, driveway, shop, or even off-site - as long as you've got a flat surface to work on.
General
| Material | Steel |
|---|---|
| Assembly Required | true |
| Portable | true |
Dimensions
| Individual Frame Weight Pounds | 114 |
|---|
Lifting Dimensions
| Lifting Height With 2 inch block Inches Rounded | 21 |
|---|---|
| Lifting Height With 3 inch block Inches Rounded | 21.75 |
| Lifting Height Stacked blocks Inches Rounded | 24 |
| Maximum Lift Point Spread Inches Rounded | 66 |
| Minimum Lift Point Spread Inches Rounded | 43 |
Lifting Capacity
| Lifting Capacity Pounds | 8000 |
|---|
Rise
| Time to Full Rise sec | 26 |
|---|
Locking Dimensions
| Locking Position Qty | 2 |
|---|---|
| Lock Release Type | Single-Point safety release |
Power
| Horse power | 1 |
|---|---|
| Voltage | 110V 50/60HZ 1PH |
| Amps | 10 |
| Motor | 110V, 60Hz, 1-PH |
| Noise dB | 70 |
| Power Unit | 110V, 50-60Hz, 1-Ph. |
| Watts | 1100 |
| Motor RPM | 3450 |
