Rotary R200 : Swing Arm Pro - High Volume Tire Changer with Helper Arm (110v)

Write a Review
$8,959.00
SKU: ROT.CR200R0.202109
Adding to cart… The item has been added
Description

Swing Arm Pro - High Volume Tire Changer with Helper Arm

  • Rugged, Extra Large Chassis
  • Hand Operated Double-acting bead breaker cylinder
  • Table inflation system
  • Equipped with 6.9 Gallon air tank in the column & valve tray
  • Inside clamping 12"-28.5" / Outside clamping 10"-26"• Max. Tire Diameter: 52"
  • Max. Tire Width: 16"

Scope of Delivery:

  • tub paste w/ brush
  • (4) clamp protectors
  • bead breaker blade protector
  • tool protection kit, bead lever
  • plastic mount/demount headSite
  • Requirements: 110v, 115-145 psi air supply, 115-145 psi air supply



Specifications

Specifications:

  • Turntable Speed : Variable 0-14 RPM
  • External Clamping : 10"-26"
  • Internal Clamping : 12"-28"
  • Max Torque : 885 ft lbs.
  • Max Tire Diameter : 52"
  • Max Tire Width : 16"
  • Max Bead Breaker Opening : 2"-18"
  • Bead Breaker Power : 6,745 lbs
  • Power Supply : 2HP / 110V / 1 Phase / 60hz
