GRACO 2008088 : Hydraulic Dyna-Star 10:1 Pump Module - 60 lb

Write a Review
$5,150.00
SKU: 2008088
Type: Hydraulic Pumps
Type: Grease Pumps
Ratio: 10:1
Series: DYNA-STAR
Drum Capacity: 60 lb
Adding to cart… The item has been added
Description

Graco’s 5:1 and 10:1, hydraulically-powered lubrication pumps designed for long life and reliable operation in demanding off-road mobile applications. Hydraulic Dyna-Star pumps provide reliable, quiet, ice-free performance at maximum pressure and low flow rates and are up to three times more energy efficient than comparable compressed-air systems.



Electric pumps for heavy duty automatic lubrication and transfer systems.

  • Uses up to 3 times less energy than pneumatic systems
  • Fewer moving parts reduces pump wear and maintenance
  • Self-lubricating for long-life and dependable operations
  • Ultra-quiet hydraulic motor
  • Graco's reciprocator piston minimizes change-over stalls
  • No assembly required, fits in a standard 120 lb (55 kg) grease drum
  • Lighter, more compact design than competition
  • Easy to connect, low-pressure hydraulic input
Specifications
Air Inlet Size (in)1/4
Fluid Outlet Size (mm)12.7000
Air Inlet Size (mm)6.35
Maximum Fill Inlet Pressure (kPa)4140
Maximum Fill Inlet Pressure (psi)600
Maximum NLGI Grade#2
Maximum Fill Inlet Pressure (bar)4.14
Maximum Working Pressure (psi)7500
ModelDyna-Star
Overall Height (in)33.9
Overall Height (mm)861
