GRACO 133480 : IM20P Electronic Pulser Output In-Line Meter, 3/4 '' in Ports, NPT

Write a Review
$950.00
SKU: 133480
GPM: 20
Type: In-line Meters
Series: IM
Inlet Size: 3/4 in.
Adding to cart… The item has been added
Description

The IM20P wired electronic meter delivers precise in-line dispenses for in-plant, industrial and other applications. Its heavy-duty aluminum exterior and sealed electronics protect against corrosion inside or outside the plant. Designed and manufactured by a proven leader in meter technology, it’s capable of flow rates up to 20 gpm (75.7 lpm) for optimal performance.

Typical applications include heavy-duty mobile service trucks, mining and in-plant.

  • High Flow - Flow rates up to 20 gpm (75.7 lpm) for faster dispense.
  • Sealed Electronics - Meters are suitable for indoor or outdoor use. IP69K rated.
  • Rugged Aluminum Body - Remains corrosion free in harsh environments for years of trouble-free service.
  • Large Inlet and Outlet Porting - Minimal pressure drop to increase production.
  • Wired Convenience - Easily integrated with PLC (programmable logic controller).
Specifications
Inlet Size (cm)1.905
Inlet Size (in)0.75
Inlet Size (mm)19.05
Maximum Flow Rate (L/min)75.7
Maximum Operating Temperature (°C)82
Maximum Operating Temperature (°F)180
Maximum Working Pressure (bar)102
Maximum Working Pressure (psi)1500
Meter Accuracy (%)±0.5
Minimum Flow Rate (GPM)0.25
Minimum Flow Rate (L/min)0.95
Outlet Size (in)0.75
Dispense TypePreset
Maximum Working Pressure (MPa)10
pulse_outputYes
