GRACO 120601 : 4-Way Evacuation Valve - 1-1/2" NPT(F) - 200 PSI

Write a Review
$803.00
SKU: 120601
Adding to cart… The item has been added
Description

The 4-way evacuation valve is a directional control valve used to simplify the filling and emptying of tanks. Typical applications include filling and emptying waste containers on lube trucks and transferring fluids from bulk supply tanks to operational day tanks. Typical fluids handled include petroleum and synthetic-based oils, fuels, anti-freeze and windshield wash fluid.

  • Simplifies installation by eliminating need for multiple valves
  • Unrestricted flow - no pressure or volume loss
  • Two position tank fill and emptying control
  • Tapered, self-seating valve spool for superior sealing performance
  • Four (4) 5/16 inch threaded bolt holes for flush mount installation
Specifications
Thread Size (in)1-1/2
Overall Width (mm)120.65
Overall Width (in)4.75
Overall Width (cm)12.065
Overall Height (mm)120.65
Overall Height (in)4.75
Maximum Working Pressure (bar)14
Maximum Working Pressure (kPa)1400
Maximum Working Pressure (MPa)1.4
Maximum Working Pressure (psi)200
Overall Height (cm)12.065
