BendPak RANGER RML-1500XL : Motorcycle Lift Platform With Front Wheel Vise - Deluxe Extended

Write a Review
$3,295.00
SKU: 5150605
Style: Extended
Adding to cart… The item has been added
Description



  • A combination of power, solid construction, and user-friendly features makes the Ranger RML-1500XL the best motorcycle lift money can buy.
  • With little effort, you can easily position, secure and raise motorcycles, bobbers, stretched choppers, trikes and other wheeled and recreational vehicles with ease.
  • Features 12-gauge welded-steel construction, a non-skid diamond-plate platform surface and full travel automatic safety locks that allow various working heights.
  • Side decks can be easily removed to provide a more compact work area for closer access to bikes when performing maintenance work or cleaning detail.
  • A humongous 1,500-lb. lifting capacity handles just about anything that rolls.
  • Safe and reliable means it’s been lifecycle tested beyond industry standards.
  • Retractable, built-in, full-swivel casters provide stow-and-go capability even when loaded.
  • Precision ball bearings improve rollability and are maintenance free.
  • A gentle slope, textured diamond-plate approach ramps, and a secondary cheater ramp means even ground huggers can be loaded effortlessly.
  • The RML-1500XL gets its power from a potent commercial-grade hydraulic power system that produces big lifting muscle right off the ground.
  • A dual-function power unit provides either air or hydraulic pump operation.
  • User-friendly controls increase productivity, reduce injuries, save money, and improve job satisfaction.
  • A wide base frame combined with full perimeter tie-down rings provides a stable work environment ensuring bikes and choppers remain upright; tip-over concerns remain a thing of the past.
  • Chrome alloy hydraulic cylinder provides smooth, controlled operation to keep things nice and civilized, and an extended-stroke ram means the RML-1500XL stands tall for improved ergonomics.
  • A rigid tubular-steel wheel vise provides better stability and features a hardened steel crank and ergonomic handle for fast and easy set-up. Durable non-slip rubber contact plates help protect expensive wheels.
  • A removable rear deck provides drop-down clearance and accessibility for wheel and suspension work.
  • A secondary rear deck with built-in dyno-rollers makes easy work out of wheel rotations and turns your motorcycle lift platform into a motoring test simulator.
  • Rear vertical support poles provide a secure and stable support for hoist straps, as well as tie-downs for elevated bike testing or other floating required services.
  • A removable tool and parts tray can be positioned at multiple Quick-Lock positions located on the perimeter of the lift platform.
Specifications
Overall Length
with Extension and Ramp
141.8 in. / 3,603 mm
Overall Length
with Ramp, No Extension
123.75 in. / 3,142 mm
Overall Width
with Side Extension Decks
53.3 in. / 1,354 mm
Overall Width
No Side Extension Decks
31.9 in. / 810 mm
Lowered Height
7.5 in. / 188 mm
Full Rise - Top Deck
45.3 in. / 1,153 mm
Top of Stand Poles at Full Rise
108 in. / 2,740 mm
Top Deck – 1st Lock Position
24.5 in. / 625 mm
Top Deck – 6th Lock Position
7.75" (197 mm)
Lifting Capacity
1,500 lbs. / 680 kg
Air Supply
40 to 120 psi at 98 to105 in/3
Power Supply / Pump
Compressed Air / Hydraulic
Shipping Weight
808 lbs. (367 kg)
Shipping Dimensions
46'' x 91'' x 16'' (1,168 mm x 2,311 mm x 406 mm)
