BendPak RANGER RWS-200WL : Portable Off-Center High-Speed Tire & Wheel Lift - Rechargeable Battery - 200 Lb. Cap.

Write a Review
$1,500.00
SKU: 5150087
Capacity: 200
Adding to cart… The item has been added
Description
  • Reduces Risk of Lifting Injuries – Minimizes strain, sprains, and repetitive motion injuries associated with lifting heavy tires and wheels
  • Helps Prevent Common Workers’ Comp Claims – Protects technicians from one of the most common shop-related injury types
  • OSHA-Friendly Safety Practices – Shows compliance with OSHA 29 CFR 1910.176 (handling of materials) and 29 CFR 1910.132 (PPE and ergonomic hazards)
  • 200-lb. (90.7 kg) Lifting Capacity – Handles oversized, heavy-duty and performance wheels with ease
  • Battery-Powered 24VDC Linear Actuator – Delivers smooth, controlled lifting with zero air or wall power required
  • 44.8Ah Industrial Lithium-Ion Battery – Provides long runtime with up to 1000 charge cycles for years of dependable use
  • No Air Lines. No Power Cords. No Hazards. – Unlike pneumatic or 110V lifts, the RWS-200WL operates without tethered hoses or cords, eliminating tripping hazards, tangled lines, and shop clutter. No need to drag cables or hunt for outlets – just charge and go.
  • Fast Lift Speed: 1.6 in/sec – Boosts productivity while maintaining safe, steady motion
  • One-Touch Control Panel – Simple UP/DOWN buttons ensure intuitive operation for any technician
  • Integrated Safety Tie-Down Strap – Keeps wheels restrained in place during lifting and transport
  • Powder-Coated All-Steel Construction – Built to withstand daily abuse, corrosive chemicals, and shop hazards
  • Compact Base with Heavy-Duty Casters – Moves easily around tight bays; two locking casters keep the lift firmly in place
  • Oversized Roller Assembly – Supports large wheels securely, helps technicians align easily
  • Stable Nylon Slide Blocks – Minimize friction and wear on the lift post for smoother operation and longer life
  • Low-Profile Base Frame – Wheels roll easier into position during set up. Fits under low ground-clearance vehicles.
  • High-Productivity Precision Use – Ideal for tire shops, EV service bays, fleet facilities, and OEM service departments
  • Global Battery Charger – Accepts 100–240VAC input; no adapters required in most regions
  • Tool-Free Setup and Maintenance – Designed for easy assembly and long intervals between maintenance checks
  • Battery Status Indicator – Displays remaining battery life automatically when powered on.
  • 12V DC Output – Provides convenient power for accessories or small tools.
Specifications
Max. Lift Capacity
200 lbs. (90.7 kg)
Lift Range (at rollers)
2.5 in. – 45 in. (65 mm – 1140 mm)
Max. Extended Height (tip)
85.25 in. (2,165 mm)
Base Footprint (L × W)
30 in. × 27 in. (760 mm × 686 mm)
Roller Spacing (center-to-center)
12.5 in. (318.75 mm)
Raise/Lower Speed
1.6 in./sec (40 mm/sec)
Battery Type
24 VDC Lithium-Ion
Battery Capacity
44.8 Ah
Battery Runtime
Up to 1000 charge cycles (at ≤ 5 A)
Charger Input Voltage
100–240 VAC, 50–60 Hz
Charger Output
29.4 VDC @ 0.95 A
Operating Temperature Range
32 °F – 113 °F (0 °C – 45 °C)
Caster Size
3 in. (Two swivel, two locking)
Unit Weight (assembled)
132 lbs. (60 kg)
