Specifications
Specifications
Specification | SL210-RA | SL210-TA |
Adapters | Round | Truck |
Rise | 75 7/8″ – 81 3/8″ | 75 7/8″ – 81 3/8″ |
Width Overall | 108 1/4″ | 108 1/4″ |
Drive-Thru Clearance | 88″ | 88″ |
Reach (min.) | 19 1/4″ | 19 1/4″ |
Reach (max) | 41 1/4″ | 41 1/4″ |
Reach (overall arm min.) | 54 1/2″ | 54 1/2″ |
Reach (overall arm max.) | 99″ | 99 |
Min. Adapter Height | 4 1/4″ | 4 1/4″ |
Low Step Height | N/A | N/A |
High Step Height | 5 3/8″ | 5 3/8″ |
Lifting Capacity Overall | 10,000 lbs. | 10,000 lbs. |
Lifting Capacity (per arm) | 2,500 lbs. | 2,500 lbs. |
Guide Plunger Diameter | 8 1/2″ | 8 1/2″ |
Voltage Single Phase | 208v – 230v | 208v – 230v |
Time of Full Rise/Decent | 53 secs. / 24 secs. | 57 secs. / 29 secs. |
Min. Bay Size | 11’x24′ | 11’x24′ |
Specifications
Capacity 10000
