EZDS Zenith Z5 : Diagnostic System

Name: EZDS Zenith Z5 : Diagnostic System
Brand: EZDS
SKU: EZZ5
Price: 1450 USD
Availability: InStock

EZDS

$2,495.00

Now: $1,450.00

Write a Review

SKU:: EZZ5

Product Description

The EZDS Zenith Z5 is a compact, ruggedized 8" industrial tablet made by the same company that brought you the GSCAN, GSCAN2 and GSCAN2. Running on Android 9 OS with a 2.0Ghz octa-core processor, the Z5 offers quick boot-up and intuitive menu selection. The tablet provides a crystal-clear, field optimized display in bright sunlight conditions. It includes advanced graphing, recording and logging of vehicle data analysis; fast glitches can be easily monitored, saved and reviewed.

The Z5 can also be used as a J2534 Pass thru device. Connect it to your laptop with manufacturer software for OE diagnostics and programming.

The Zenith Z5 supports 12 and 24v vehicles with Bi-Directional functionality to perform the following functions:

Common Service functions such as

ADAS calibration
Brake Pad Replacement
Engine Oil Reset
Brake Air Bleeding
Battery Reset
Steering Angle Sensor CalibrationDPF regeneration
Key programming
Electronic parking brake service mode
Transmission relearn
Module coding and programming
Wi-Fi Updates
Wireless Printing
Pre/Post Scan Reports
Replacement battery (sold separately) that is easy to install and will not void the current or future warranty

The Pre/Post scan diagnostic report function provides an intuitively designed diagnostic report that can be created quickly and easily, including workshop and customer details, diagnostic trouble codes, saved image files, camera images, personalized notes, etc.

Specifications

Specifications

Fast Performance CPUA powerful octa-core processor for optimum diagnostic performance and fast operation to perfectly manage workshop conditions.
Smart Operating SystemBased on Android 9 OS providing quick boot-up, multi-tasking, fast networking and enhanced system security.
Eyellumicate™ 8” LCDEyellumicate™ Display LCD provides a crystal clear view both indoors and out, offering field-optimized display under bright workshop environment.
Eyellumicate™ Display TechnologyEyellumicate™ Display technology enhances touch functionality and allows technicians to perform tasks with work gloves on under any harsh workshop conditions.
Service FunctionDiagnostic software programmed by engineers with automotive technicians in mind. Regular and urgent on-demand software updates bring diagnostic confidence to the user.
J2534 Pass-thruZenith Z5 functions as a J2534 ‘Pass-Thru’ device for programming the ECUs for multiple carlines.
24V Commercial VehiclesZenith Z5 hardware accepts power & signals of a 24V system, and supports Bi-directional communications with commercial trucks and buses.
Wireless ConnectivityRobust connectivity allows for smart updates, quick feedback, Teamviewer Support, Bluetooth printing, browsing and much more.
Pre & Post Diagnostic ReportAn intuitively designed diagnostic report function for fast and easy creation of the report on pre and post scan results.
Lightweight, Robust DesignCompact, yet rugged. Ergonomic size to hold in one hand for long periods of time. Zenith Z5 is a light weight scan tool (680g or 1.5 lbs) with sleek, ruggedized design.

Category	Specifications
CPU	Octa Core Processor @ 2.0 GHz
Operating System	Android 9
System Memory	Internal 32GB, RAM 3GB
External Memory	Micro SD Card
LCD	8.0 inch FHD (1920 x 1200)
Input Devices	Capacitive Touch Screen, 3 Hard Keys (Power, Volume +, Volume -)
Camera	8 megapixel auto-focus with LED flash
Sound	Loud Speaker \| 1 Microphone; 3.5 pi standard audio jack
Rechargable Battery	Li-ion 3.8V 3200mAh
Operating Voltage	DC9 ~ 30V
Sensors	Ambient Light, Proximity, Gyroscope, Accelerometer
Dimension	225 x 136 x 33mm
External Port	USB 1ea, USB C 1ea
Network	RJ45 Ethernet, WiFi 802.11 a/b/g/n, B/T
