Challenger BT3300 : Lift Table 3300 LB
$11,310.84
SKU:
BT3300
Used to facilitate and safely perform the installation and removal of EV batteries, electric car battery packs, transmissions, gearboxes, clutches, engines and various components of the car chassis.
- Scissor-style lifting
- Hydraulic cylinder
- Max reachable height 76.5”
- Easy maneuvering, thanks to pallet-jack style handle
- Extending, adjusting and tilting top plate
- Plugs in to any 120v outlet
- Power cord included
- Complies with ASME PASE-2019
| BT3300 | SPEC |
|---|---|
| Lifting Capacity | 1500Kg / 3307lbs |
| Rise Height | 1950mm / 76.77" |
| Collapsed Height | 750mm / 29.53" |
| Platform Adjust Height [S] | 45mm / 1.77" |
| Platform Length | 1741-2066mm / 68.54“- 81.34" |
| Platform Width | 800mm / 31.50" |
| Platform Height | 229 (±45)mm / 9.02" (±1.77") |
| Deck Length | 1500mm / 59.06" |
| Base Height | 205mm / 8.07" |
| Wheel Diameter | Ø200mm / 7.87" |
