Beissbarth MS 670SL-BP : Premium Leverless Tilt-Back Tire Changer w/ NG2 Technoroller

Write a Review
$11,177.31
$8,382.98
SKU: 1694201482-BP
Type: Leverless
Type: Tilt-Back
Clamping: Center-Clamp
Power: Electric
Adding to cart… The item has been added
Description
Beissbarth MS 670S Leverless tilt-back tire with center clamp is a premium performance solution for those looking to increase efficiency and reduce damage to challenging wheel assemblies. The center clamping design greatly reduces metal contact, and provides for clear access to the bottom of the assembly when servicing difficult tires.

Key Features:
  • Tilt back G-frame design
  • Single button locking for automatic positioning of mount head
  • Leverless demount head for simple, fast, controlled process
  • Clamping range 13" to 30"
  • NG2 Tecnoroller - Tri-power Bead Press System
  • 2 year parts and 1 year labor warranty

Standard Accessories:
  • 1 Bead lever
  • 1 Lubricant brush
  • 1 Bead pressing device
  • 1 Bead breaker plastic protection
  • 5 Mount / demount head protectors
  • 1 Wing side protection for demount head
  • 1 70mm Cone
  • 2 Cone protector tool locking system
  • 2 Center locking protection
  • 2 pin protection locking system
  • Tool Holder (1 695 108 913)
Specifications
  • Wheel diameter max.     1200 mm
  • Bead breaking range       75 - 401 mm
  • Bead breaker force          11 kN
  • Compressed air connection         8 - 10 bar
  • Weight 390 kg
  • Rim width max. 15 "
  • Rim diameter max.          30 "
  • Depth   1950 mm
  • Height   2400 mm
  • Power supply     230 V | 50 Hz | 1 ph
  • Width    2000 mm
  • Rim diameter min.           13 "
  • Rotation speed 7 - 15 rpm
  • Number of mounting speeds      2
