Beissbarth MS 670SL-BP : Premium Leverless Tilt-Back Tire Changer w/ NG2 Technoroller

Name: Beissbarth MS 670SL-BP : Premium Leverless Tilt-Back Tire Changer w/ NG2 Technoroller
Brand: Beissbarth
SKU: 1694201482-BP
Price: 11177.31 USD
Availability: InStock

Beissbarth

$11,177.31

Write a Review

SKU:: 1694201482-BP

Product Description

Beissbarth MS 670S Leverless tilt-back tire with center clamp is a premium performance solution for those looking to increase efficiency and reduce damage to challenging wheel assemblies. The center clamping design greatly reduces metal contact, and provides for clear access to the bottom of the assembly when servicing difficult tires.

Key Features:

Tilt back G-frame design
Single button locking for automatic positioning of mount head
Leverless demount head for simple, fast, controlled process
Clamping range 13" to 30"
NG2 Tecnoroller - Tri-power Bead Press System
2 year parts and 1 year labor warranty

Standard Accessories:

1 Bead lever
1 Lubricant brush
1 Bead pressing device
1 Bead breaker plastic protection
5 Mount / demount head protectors
1 Wing side protection for demount head
1 70mm Cone
2 Cone protector tool locking system
2 Center locking protection
2 pin protection locking system
Tool Holder (1 695 108 913)

Specifications

Specifications

Wheel diameter max. 1200 mm
Bead breaking range 75 - 401 mm
Bead breaker force 11 kN
Compressed air connection 8 - 10 bar
Weight 390 kg
Rim width max. 15 "
Rim diameter max. 30 "
Depth 1950 mm
Height 2400 mm
Power supply 230 V | 50 Hz | 1 ph
Width 2000 mm
Rim diameter min. 13 "
Rotation speed 7 - 15 rpm
Number of mounting speeds 2
