Autel MD808P : MaxiDIAG All Code Reader

Write a Review
$319.95
SKU: MD808P
Type: All System Diagnostics
Application: Automotive
Category: All System Diagnostics
Adding to cart… The item has been added
Description

The MD808P is an advanced all systems code reader. It has a 4-inch color screen, can access all modules in all systems, performs AutoSCAN, and currently has 6 service functions. The MD808P can graph/record/playback live data, display live and freeze frame data, and supports all 10 OBDII test modes. It has enhanced Mode 6 diagnostics, I/M readiness/emissions testing, and performs DPF regeneration. The MD808P is updatable via PC and includes an OBDII cable. A 1-year tool warranty and free lifetime software updates are available with purchase.

Features:

  • All System AutoSCAN DTCs Detection
  • OLS/ EPB/ SBC/ SAS/ BMS/ DPF
  • Set Inspection 1&2 Service Intervals
  • I/M Readiness / Emissions Testing
  • FREE Lifetime Software (lifetime of tool) & 1Yr Warranty
  • Reads & Clears EPB/ SBC Trouble Codes
  • Support OBDII Protocols & All 10 OBDII Test Modes
  • Enhanced Mode 6 Diagnostics
  • View Live and Freeze Frame Data
  • 4" Color Display 840x480
  • Includes OBDII Cable & 16 MB Micro SD Card
  • Easy-To-Use Navigation /Software Updates via PC
Specifications
ProcessorARM® Thumb® Processor (400 MHz)
Memory32MB, 166 MHz
Display4.0 inch LCD with 800×480 resolution
ConnectivityMini USB: 2.0 Micro SD Card (16GB)
Power Consumption1.7 W
Operating Temperature-10°C to 60°C (14°F to 140°F)
Storage Temperature-20°C to 70°C (-4°F to 158°F)
Operating Humidity5% – 95% non-condensing
HousingStrong plastic housing with protective rubber boot
Dimensions (W x H x D)202 mm x 92 mm x 35 mm (8.35" x 3.62" x 1.4")
Weight313 g (0.69 lb.)
