The Beta 45 features the ability to be lift vehicles either symmetric or asymmetric position dependent upon the service requirements of your shop. The DBx 10 features 3-stage front arms that provide maximum extension and retraction ensuring safe and reliable lifting on all vehicles within rated capacity.Â
With double telescoping screw pads, stack adapters, durable powder coat finish, plated arm restraints and pins along with many other appealing features, the Beta 45 will accommodate the demands of a full service facility. Frame engagement adapters not included, available at additional charge.
Model Number | DBX10 | |
Lifting Capacity | 10,000 lbs | |
Lifting Configuration | Symmetric | Asymmetric |
Arms | 3-Stage Front / 2-Stage Rear | |
Rise Height | 72" Cyl Stroke | |
Overall Height | 141-¾" | |
Overall Height (Cylinder Extended) | 144" | |
Overall Width | 143-3/8"Â | |
Width Between Columns | 114-1/8" | |
Drive Through Clearance | 134-5/16"Â | |
Rise Time | 50 Seconds | |
CE Certified | YES | |
Colors Available | Drk Gray / Red |
