Specifications
- Color: Red/Black
- Product Type: Hydraulic Ram
- Ram Capacity (Tons): 20
- Stroke (Inch): 5.00
- Effective Area (Square Inch): 5.14
- Oil Capacity (ml): 425
- Collapsed Height (Closed) Inch: 11.1
- Ram Extended Height (Inch): 16
- Outside Diameter of the Unit (Inch): 3.23
- Diameter of the Ram (Inch): 2.36
- Saddle Diameter (Inch): 2.13
- Optimal Pressure: 8,567 PSI
- Weight (Lbs.): 20.28
- Warranty: 1 Year
- 20 Ton 5.00" Stroke - 1/4" 18 NPTF female coupler.
- Designed for use in all positions with high strength allow steel for durability.
- Heavy duty return spring allows smooth return function.
- Baked enamel finish for increased corrosion resistance.
- Collar thread protector.
- Rod wipers seal out contaminants.
- Chrome plated ram prevents rust and corrosion.
- Threaded collar and ram for easy, secure adaptation to extensions and accessories.
